3.3kW OCPP AC Charger
OCPP to provide Seamless Experience Charging Start (or) Stop via Remote Connectivity Make your charger public, and earn per hour for booking Protections - MCB Protected, Over Voltage, Under Voltage, Over Current, Surge Protection, Short Circuit, Over Temperature, Isolation Monitoring and Earth Leakage Curren
3.3kW OCPP AC Charger
"The charger's charging power output is indicated by the word "3.3 kW". It shows the speed at which the electric vehicle's battery can receive energy from the charger. AC chargers are typically used for slower charging at homes, offices, or public charging stations where longer charging durations are acceptable. When the car will be parked for a long time, a 3.3 kW charger offers a moderate charging pace that is ideal for overnight charging. It is frequently classified as Level 2 charging. Numerous electric car models are compatible with 3.3 kW AC chargers. It is imperative to verify whether the charger is compatible with the particular electric vehicle model you own."
Technical Specifications | 3.3 kW AC Charger |
---|---|
AC Nominal Input | |
Input Voltage | 230V ±10% |
Input Current | 15A Max |
Frequency | 50 Hz ± 2% |
Input Power | 3.3 kW |
AC Nominal Output | |
Output Voltage | 230V ±10% |
Output Current | 15A Max |
Over Current | 17A |
Output Power | 3.3 kW |
USER INTERFACE | |
---|---|
Support Language | English |
Charging Operation | Standalone |
Visual Indication | Presence of input supply, Error Indication, Network Connection |
User Authentication | RFID / APP |
Safety Parameters | Over current, Over Voltage, Under Voltage, Ground Fault, Surge Protection, Leakage Current Detection, Emergency Detect, Over Temperature |
Energy Meter | Inbuilt energy meter with 1% |
EVSE to EVCC | IEC61851 - 1 Annex A |
EVSE to CMS | Wi-Fi / 4G / OCPP v1.6j |
Ingress Protection | IP 56 |
Charging option | Grid Responsive Metering with 1% Accuracy |
Weight | 600g / Approx |
Chargable Devices | EV Cars, E-Bikes & Mobile Phones |
Connectivity | GSM & Wi-Fi |
Altitude | Upto 2000 meters |
Humidity | 5% to 95 % Non condensate |
